Acer Altos AT350 F3 Tower Server
Acer Altos AT350 F3 Tower Server Chennai, Hyderabad
- Processor type: Dual socket R3 (LGA 2011) supports Intel Xeon processor E5-2600 v3 & v4 family
- Chipset: Intel C612 chipset
- Graphics: ASPEED 2400, 128 MB shared video memory, 16 MB dedicated
- Memory: 16x 288 pin DDR4 DIMM slots
- Up to 1TB ECC LRDIMM, 512GB ECC RDIMM
- Expansion slots:
- 3x PCI E 3.0 x16 (Full height, Full length)
- 3x PCI E 3.0 x8 (Full height, Full length)
- Rear USB: 2x USB 3.0 + 2x USB 2.0
- Front USB: 2x USB 2.0
- I/O ports:
- USB Header: 2x 3.0, 2x 2.0, 1x Type A
- 2x RJ45 Gigabit Ethernet LAN ports
- 1x RJ45 Dedicated IPMI LAN port
- 1x VGA port
- Serial port: 1x COM/Serial
- AHCI SATA :
- 8x SATA3 (6Gbps) ports with RAID 0, 1, 5, 10
- 2x SATA3 powered ports that support SATA DOM
- Network controllers :
- Intel i350 Dual Port Gigabit Ethernet
- Virtual Machine Device Queues reduce I/O overhead
- 1x Realtek RTL8291F PHY (dedicated IPMI)
- IPMI:
- Support for Intelligent Platform Management Interface v.2.0
- IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
- ASPEED 2400
- Front Panel: Power On/Off button
- System Reset button
- Power LED
- Hard drive activity LED
- 2x Network activity LEDs
- System Overheat LED
- Power Fail LED
- 2x USB Ports
- Sub system availability:
- Power supply: 920W high efficiency ( Platinum Level ,94%+) AC-DC Redundant power supplies with PMBus and I2C
- System cooling:
- 3x 8cm hot swap redundant PWM cooling fans
- 2x 8cm hot swap exhaust Fans and air shroud
- Drive Bays
- 8x 3.5 Hot-swap SAS/SATA Drive Trays
- 2x 5.25 Peripheral Drive Bays
- 1x 5.25 Bay that fits 3.5" bay devices
- Chassis:
- Form factor: 4U Rackmountable/ Tower, Optional Rackmount Kit
- Dimensions (WxDxH): 7.0 (178mm) x 25.5 (648mm) x 17.2 (437mm)
- Weight:
- Net Weight: 56 lbs (25.6 kg)
- Gross Weight: 73.5 lbs (33.6 kg)
- Operating System support: Windows Server2008, Windows Server 2008 R2
- Windows Server 2012, Windows Server2012R2
- Red Hat Enterprise Linux 7, VMware ESXi 5.5U2
