Cisco Catalyst 9117 Access Point
Cisco Catalyst 9117 Access Point Chennai, Hyderabad
- Three radios: 2.4GHz (4x4), 5GHz (8x8), and BLE, Supports OFDMA and MU-MIMO, Internal antenna
- Software: Cisco Unified Wireless Network Software Release 8.9 or later
- Cisco IOS XE Software Release 16.11 or later
- Supported wireless LAN controllers: Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3500, 5520, and 8540 Series Wireless Controllers, and Cisco Virtual Wireless Controller
- 802.11n version 2.0 (and related) capabilities
- 8x8 MIMO with four spatial streams for 5 GHz band
- 4x4 MIMO with four spatial streams for 2.4 GHz band
- Maximal Ratio Combining (MRC)
- 20- and 40-MHz channels
- PHY data rates up to 600 Mbps (40 MHz with 5 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- Cyclic Shift Diversity (CSD) support
- 802.11ac
- 8x8 downlink MU-MIMO with eight spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80, and 160 MHz channels
- PHY data rates up to 3.5 Gbps at 5 GHz
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- CSD support
- 160 MHz support only on 4 spatial stream
- 802.11ax
- 8x8 MIMO with eight spatial streams for 5-GHz band
- 4x4 MIMO with four spatial streams for 2.4-GHz band
- Downlink OFDMA
- TWT
- MRC
- 802.11ax beamforming
- 20-, 40-, 80, and 160 MHz channels
- PHY data rates up to 5 Gbps at 5 GHz
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- CSD support
- Integrated antenna: 2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth
- 5 GHz, peak gain 6 dBi, internal antenna, omnidirectional in azimuth
- Interfaces: 1x 100, 1000, 2500, 5000 Multigigabit Ethernet (RJ-45)IEEE 802.3bz
- Management console port (RJ-45)
- USB 2.0 with up to 4.5W (enabled via future software)
- Indicators: Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
- Dimensions (W x L x H)
- Access point (without mounting bracket and mounting features): 8.70 x 8.70 x 1.94 in. (22 x 22 x 4.93 cm)
- Access point (without mounting bracket): 8.70 x 8.70 x 2.19 in. (22 x 22 x 5.56 cm)
- Weight: 3.02 lb (1.4 kg)
- System memory: 2048 MB DRAM, 1024 MB flash
- Warranty: Limited lifetime hardware warranty
