- Defend applications and data before your server is built with the new HPE Trusted Supply Chain offering.
- Supporting additional second generation Intel Xeon Scalable processor family offerings.
- Increased Single-Width GPU Density with up to 7 NVIDIA Tesla T4 16GB Computational Accelerators or 7 Xilinx Alveo U50 Accelerators supported in a standard-depth 2U rack form factor
- Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
- Intel Optane persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB.3
- iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.
Specification:
Management Software:
Infrastructure management: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional; requires licenses)
Security:
Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Server Controllers:
Network controller: HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model
Storage controller: 1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
Server Cooling:
System fan featuresHot-plug redundant fans, standard
Server Drives:
Drive supported8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD; 2 M.2 SATA SSD standard on primary riser, depending on configuration; 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional; 20 SFF NVMe optional; NVMe support via Express Bay will limit maximum drive capacity
Server Expansions:
Expansion slots: 8
Server Form Factor:
Form factor:2U Rack
Server Memory:
Memory type: HPE DDR4 Smart Memory with optional Intel Optane persistent memory 100 series for HPE, depending on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors, and the 4215R and 4215 processors.
Maximum memory:3.0 TB with 128 GB DDR4, depending on processor model; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model
Memory slots:24 DIMM slots
NVDIMM type: HPE NVDIMM-N *Only available on 1st Generation Intel Xeon Scalable Processors
NVDIMM rank: Single rank
NVDIMM capacity:16 GB
Processor:
Processor type: Intel
Processor family: Intel Xeon Scalable 8100/8200 series Intel Xeon Scalable 6100/6200 series Intel Xeon Scalable 5100/5200 series Intel Xeon Scalable 4100/4200 series Intel Xeon Scalable 3100/3200 series
Processor number: 1 or 2
Processor core available4 to 28 core, depending on model
Processor speed3.9 GHz, maximum depending on processor
Processor cache8.25 - 38.50 MB L3, depending on processor model
Warranty:
Warranty3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage.
Weights and Dimensions:
Weight:14.76 kg (32.6 lb)
Dimensions:44.55 x 73.03 x 8.74 cm (17.54 x 28.75 x 3.44 in)
